Description
Overview
The Axisflying MANTA5 SE DeadCat-DC is a 5-inch FPV freestyle drone engineered for performance, stability, and long-range HD visuals. Designed with an innovative CNC aluminum and T700 carbon fiber frame, this BNF drone integrates the DJI O4 Air Unit Pro, front-mounted GPS, and AE2207 V2 motors, delivering a top-tier flight experience for freestyle and cinematic pilots alike. With optimized stack compatibility and robust durability, the MANTA5 SE DC is your go-to choice for precise control and creative freedom.
Key Features
-
Innovative DeadCat Frame: CNC aluminum side plates and T700 carbon fiber structure provide high strength and camera protection, optimized for freestyle and cinematic flights.
-
DJI O4 Pro Air Unit: Equipped with a 1/1.3” image sensor, 4K/120FPS video, 155° ultra-wide FOV, and up to 15km transmission range.
-
AE2207 V2-1960KV Motors: Powerful and responsive for advanced freestyle maneuvers like Sbang, Flow, and Bando.
-
Argus ECO F722 + 60A ESC Stack: Plug-and-solder-friendly golden combo supports all stack peripherals with precision.
-
Front-Mounted Ublox M10 GPS: Ensures faster satellite locking (up to 32 satellites) and failsafe activation.
-
Built-In Beeper: Audible alerts for drone retrieval and crash location, reducing recovery time.
Product Specifications
| Item | Details |
|---|---|
| Product Name | Axisflying Manta 5 SE DC |
| Frame | Axisflying Manta 5 SE DC Frame |
| Wheelbase Size | 226mm |
| Weight | 454g ±10g |
| Top Plate Thickness | 2mm |
| Center Plate Thickness | 3mm |
| Bottom Plate Thickness | 3mm |
| Arm Thickness | 6mm |
| Flight Controller | Axisflying Argus ECO FC F722 |
| ESC System | Axisflying Argus ECO ESC 60A-6S (Bluejay 8 Bit) |
| Gyroscope | ICM-42688-P |
| VTX | DJI O4 UNIT PRO |
| Motors | AE2207 V2 – 1960KV |
| Propellers | 4.93.33 |
| Battery Interface | XT60 |
| Receiver Options | TBS Nano RX / ELRS 2.4G / ELRS 915 |
| Recommended Battery | LIHV / LIPO 1050-1300 mAh 6S |
Recommended Configuration
-
Motors: Axisflying C246 or AE2207 V2
-
Propellers: Axisflying / Gemfan / HQ 4.9”–5.1” freestyle props
-
Lipos: 1050–1500mAh 6S
-
Stack: Axisflying ArgusPRO 55A/F7
Packing List
- FPV Drone ×1
- Propellers ×2 bags
- VTX Antenna ×1
- L-shaped Wrench (M2 & M3) ×1
- Spare Battery Anti-slip Sticker ×1
- Spare Battery Straps
- GoPro Fixing Screws (with Nuts)
- Quick Start Guide ×1
- GPS Instruction Manual ×1
